I have been working on a dataframe plot, where I have 2k values to show and its indexes. However, when I try to plot them, obviously, matplotlib tries to squeeze all the index labels in the axis, making it impossible to read. It looks like this:

I have tried to increase figsize, but there are just too much xticks. Since the data is not linear (there are maybe 900 values between 0 and 1, 600 values between 1-100 and the rest >100), I cannot just re-arange the xticks with `np.arange()`

, since the data loses correlation (there are 2k bars, but the last index is 1534.34). If I try `xticks=np.arange(0, max1, max1/20)`

to get 20 ticks evenly spaced, I get this result:

Which obviously, is not true, since like I said, the max index is 1534.34, so that the last tick should be at the very end of the horizontal axis. Also, as as said, the first 900 values are between 0 and 1, and this is not true in the plot.

I don’t know if I’ve been clear enough or this question is adequate, but this is my first question and I have tried to. So don’t be too harsh please. However all criticism is welcomed. Thanks.

## Answer

I use `ax.xaxis.set_major_locator(ticker.MaxNLocator(interval))`

to set my ticks on the x axis after defining the interval as some integer. See documentation here. I think this relies on calling the graph in a form such as:

fig = plt.figure(figsize = (5,2)) ax = fig.add_axes([0, 0, 1, 1])
